General Questions and Answers about Youwei GPS Modules

What is the accuracy of this GPS module?

Generally the horizontal accuracy is 2.5m to 5 meters

Does this module support both GPS and GLONASS (or other satellite systems like Galileo, BeiDou)?

Yes, it supports dual systems, Youwei provide GPS, SBAS, QZSS, GLONASS, BeiDou, Galileo for options, you can choose any two.

What is the update rate (refresh rate) of the GPS module?

It is an optional parameters, option range from 1Hz to 10Hz.

What is the time-to-first-fix (TTFF) under different conditions (cold/warm/hot start)?

Hot start: 1 second typical

Warm start: 28 seconds typical

Cold start: 30 seconds typical

Does this module have an internal antenna, or does it require an external one?

The GPS module is designed for use with passive and active antennas, internal antenna or external antenna. It is selectable as per order.

What is the operating voltage range of the module?

Default 3V ~ 5V

What communication interfaces does it support (UART, I2C, SPI, USB, etc.)?

It supports all your mentioned interfaces and you are allowed to appoint other interfaces.

Does it come with a built-in battery for backup (for RTC or fast hot start)?

Built-in backup battery is optional as per order.

What is the maximum altitude it can track?

The max. altitude is 18000 meter.

Can it work indoors or under weak signal conditions?

Yes, high sensitivity, multi-systems, active/external antenna, aid technology and excellent anti-jamming performance ensure the GPS module can work indoor or under weak signal condition normally.

What is the operating temperature range?

Typically -40°C to +85°C

Is it waterproof or resistant to harsh environments?

Does it output NMEA sentences? Can it be customized?

Yes, NMEA 0183 standard sentences, and YOUWEI provide GGA, GLL, GSA, GSV, RMC, VTG, ZDA, ANT, DHV, LPS, UTC, GST etc. for options.

Is there any configuration software or SDK provided?

Yes, it is available.

Does it support differential GPS (DGPS) or RTK for higher accuracy?

Yes, it is available for your option.

Can it be used for geofencing applications?

Yes, it supports geofencing.

Are there any open-source libraries or example codes available?

Yes, they are available.

What is the warranty period?

Youwei provide 12 months warranty for the GPS module and whole life after-sale service and technology support.

Do you provide a datasheet and pinout diagram?

Yes, they are available on request.

Can I get technical support if I face issues during integration?

Yes, timely and effective technical support is one of the key advantages we thrive on.

Do you offer bulk discounts for large orders?

Yes, price for large qty is negotiable.
