Created with Pixso. YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity
YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity
  • name
  • name
  • name
  • name
  • name
  • name

YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity

Model Number: YW-198G3
MOQ: 1
Price: $3.50-4.50
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Dimensions:
38mm*49mm*16mm
Frequency Band:
L1+L5
Sensitivity:
-130 DBm To -160 DBm
Positioning Accuracy:
1cm To 3cm
Communication Interface:
USB, I2C, SPI, Uart
Operating Temperature:
-40 To 85℃
Chipset:
GK-9501
Baud Rate:
9,600 Bps
Channels:
66
Cold Start Time:
29 Seconds
Warm Start Time:
28 Seconds
Hot Start Time:
1 Second
Maximum Altitude:
50,000 Meter
Maximum Velocity:
515 M/s
Navigation Update Rate:
1 Hz
Highlight:

YOUWEI GK-9501 GNSS module

,

GNSS module with -160dBm sensitivity

,

38mmx49mm GPS module

Product Description
High Sensitivity Type-C GPS Module with G-Mouse Molex Connector

Efficient consumption car recorder antenna integration with superior tracking performance and fast positioning.

GPS Receiver Specifications
Chip MediaTek GK9051 (Rom Version)
Frequency L1 frequency band
Code C/A Code
Protocol NMEA 0183 v4.1
GALILEO L1 open service (with upgrade)
Default: GGA,GSA,GSV,RMC
Support: VTG,GLL,TXT ublox binary and NMEA Command
Available Baud Rate 9,600 bps
Channels 66
Sensitivity Tracking: -161dBm
Reacquisition: -160dBm
ColdStart: -147dBm
Start Times Cold Start: 29 seconds average
Warm Start: 28 seconds average
Hot Start: 1 second average
Accuracy Horizontal Position: Autonomous <2.5m average, SBAS < 2.0m average
Velocity: 0.1 m/s
Timepulse signal: RMS 30 ns
Maximum Altitude 50,000 meter
Maximum Velocity 515 m/s (1000 knots)
Dynamics 4G
Max navigation update rate 1 Hz (Default 1Hz)
Packaging & Shipping
YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 0
Our Services
Expert Consultation

Our professional team provides comprehensive information about products, industry trends, and market dynamics.

Customized Solutions

We offer tailored product specifications, packaging, and service packages to meet your specific requirements.

Order Tracking

Regular updates on production progress, estimated completion time, and shipping details throughout the fulfillment process.

Quality Assurance

1-year warranty with full responsibility for quality-related issues and prompt resolution by our after-sales team.

Technical Support

Comprehensive services including installation guidance, maintenance advice, and technical training.

Return Policy

Hassle-free return or exchange process within specified period of receiving the product.

Company Information
YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 1
FAQ
YOUWEI GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 2
Tags:

rtk gps module

gps receiver module

high precision gps module
