Created with Pixso. Youwei GNSS Module GK-9501 38mmx49mm GPS L1+L5 Band 1m Accuracy
Youwei GNSS Module GK-9501 38mmx49mm GPS L1+L5 Band 1m Accuracy
  • name
  • name
  • name
  • name
  • name
  • name

Youwei GNSS Module GK-9501 38mmx49mm GPS L1+L5 Band 1m Accuracy

Model Number: YW-168G3
MOQ: 1
Price: $3.50-4.50
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Dimensions:
38mm*49mm*16mm
Frequency Band:
L1+L5
Sensitivity:
-130 DBm To -160 DBm
Positioning Accuracy:
1m To 3m
Communication Interface:
USB, I2C, SPI, UART
Operating Temperature:
-40 To 85℃
Battery Type:
Internal Back-up Battery
Chipset:
GK-9501
Baud Rate:
9,600 Bps
Channels:
66
Cold Start Time:
29 Seconds
Warm Start Time:
28 Seconds
Hot Start Time:
1 Second
Maximum Altitude:
50,000 Meter
Maximum Velocity:
515 M/s
Highlight:

GNSS module L1+L5 band

,

GPS module 1m accuracy

,

compact GPS module 38mmx49mm

Product Description
Molex Connector UART TTL GNSS Receiver High Accuracy GPS/QZSS GLONASS BeiDou B1 Latest Model GPS Modules
Technical Specifications
Chip MediaTek GK9051 (Rom Version)
Frequency L1 frequency band
Code C/A Code
Protocol NMEA 0183 v4.1
GALILEO L1 open service (with upgrade)
Default: GGA,GSA,GSV,RMC
Support: VTG,GLL,TXT ublox binary and NMEA Command
Available Baud Rate 9,600 bps
Channels 66
Sensitivity Tracking: -161dBm
Reacquisition: -160dBm
ColdStart: -147dBm
Cold Start 29 seconds, average
Warm Start 28 seconds, average
Hot Start 1 second, average
Accuracy Horizontal Position: Autonomous <2.5m average
SBAS < 2.0m average
Velocity: 0.1 m/s
Maximum Altitude 50,000 meter
Maximum Velocity 515 m/s (1000 knots)
Dynamics 4G
Max navigation update rate 1 Hz (Default 1Hz)
Product Image
Youwei GNSS Module GK-9501 38mmx49mm GPS L1+L5 Band 1m Accuracy 0
