Created with Pixso. Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity
Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity
  • name
  • name
  • name
  • name
  • name
  • name

Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity

Model Number: YW-198G3
MOQ: 1
Price: $3.50-4.50
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Dimensions:
38mm*49mm*16mm
Frequency Band:
L1+L5
Sensitivity:
-130 DBm To -160 DBm
Positioning Accuracy:
1m To 3m
Communication Interface:
USB, I2C, SPI, Uart
Operating Temperature:
-40 To 85℃
Battery:
Internal Back-up Battery
Chipset:
GK-9501
Available Baud Rate:
9,600 Bps
Channels:
66
Cold Start Time:
29 Seconds
Warm Start Time:
28 Seconds
Hot Start Time:
1 Second
Maximum Altitude:
50,000 Meter
Maximum Velocity:
515 M/s
Highlight:

GNSS module with high sensitivity

,

GPS module 38mmx49mm size

,

GNSS module -160dBm sensitivity

Product Description
OEM High Precision GPS Receiver Antenna
High sensitivity GNSS receiver with Glonass and BDS support, designed for automotive and industrial applications including precision agriculture.
Technical Specifications
Chip MediaTek GK9051 (Rom Version)
Frequency L1 frequency band
Code C/A Code
Protocol NMEA 0183 v4.1
GALILEO L1 open service (with upgrade)
Default: GGA,GSA,GSV,RMC
Support: VTG,GLL,TXT ublox binary and NMEA Command
Available Baud Rate 9,600 bps
Channels 66
Sensitivity Tracking: -161dBm
Reacquisition: -160dBm
ColdStart: -147dBm
Start Times Cold Start: 29 seconds average
Warm Start: 28 seconds average
Hot Start: 1 second average
Accuracy Horizontal Position: Autonomous <2.5m average
SBAS < 2.0m average
Velocity: 0.1 m/s
Timepulse signal: RMS 30 ns
Maximum Altitude 50,000 meter
Maximum Velocity 515 m/s (1000 knots)
Dynamics 4G
Max navigation update rate 1 Hz (Default 1Hz)
Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 0 Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 1 Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 2
Packaging & Shipping
Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 3
Our Services
Expert Consultation: Our professional team provides detailed information about products, industry trends, and market dynamics.
Custom Solutions: We offer customized product specifications, packaging, and service packages tailored to your requirements.
Order Tracking: Regular updates on production progress, completion time, and shipping details throughout the fulfillment process.
Customer Support: Prompt coordination to resolve any issues and maintain clear communication during the sales process.
Quality Assurance: 1-year warranty with full responsibility for quality-related issues and dedicated after-sales support.
Technical Support: Comprehensive services including installation guidance, maintenance advice, and technical training.
Return Policy: Hassle-free return or exchange process within specified period after product receipt.
Company Information
Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 4
FAQ
Youwei GK-9501 GNSS Module 38mmx49mm with -160dBm Sensitivity 5
